| Ink |
Name: Epson UltraChrome UV Ink
Colour: Cyan, Magenta, Yellow, Black, White, Varnish
Capacity: 140 ml
Ink Type: Ink Pack
Brand Name: Epson UltraChrome UV Ink
|
| Electrical Specifications |
Rated Current: AC 100 – 240 V, 6.4 – 3.8 A
Voltage: AC 220 – 240 V, 50/60 Hz
|
| Environmental Conditions |
Temperature: Operating: 15ºC – 30ºC; Storage: -20ºC – 40ºC
Humidity: Operating: 20% – 80% (No Condensation); Storage: 5% – 85% (No Condensation)
|
| Printing |
Technology: MicroPiezo Inkjet Technology, Variable-Sized Droplet Technology
Nozzle Configuration: 1,440 nozzles (180 nozzles × 8 lines × 1 head); CMYK: 180 nozzles each colour; White / Varnish: 180 nozzles × 2 lines
Maximum Resolution: 1,440 × 1,440 dpi
Minimum Ink Droplet Volume: 5.5 pl
Printhead: MicroPiezo Printhead
Printer Language: ESC/P Raster
|
| Paper Handling |
Maximum Printing Area: 212 × 299 mm
Maximum Media Size: 210 × 297 mm
Maximum Media Thickness: 70 mm
Maximum Media Weight: 3 kg
|
| Acoustic Noise Level |
Sound Pressure Level: Approx. 60 dB
Sound Power Level: 7.5 B or less
|
| Utility Software |
Web Installer, Firmware Update, Epson Manual Launcher, Epson Edge Print PRO, Epson Edge Dashboard, LFP Accounting Tool, Epson Cloud Solution PORT (Mobile), Epson Remote Monitoring System
Epson Cloud Solution PORT
|
| Recommended System Requirements |
Windows PC: Windows 7 (32/64) or later; Epson Edge Print: Windows 11 / 10 (64-bit) / 8.1 (64-bit); CPU: Intel Core i5 3.0 GHz or higher; Memory: 8 GB+; HDD: 50 GB+ free; Monitor: 1280 × 1024 or higher
Mac: OS: Mac OS 10.6.8 or later
|
| Control Panel |
4.3” Colour Touch Screen |
| Certifications |
Safety: USA (UL), Canada (CSA), Mexico (NOM), Argentina, EU (CE), UK (UKCA), Germany (GS), Ukraine, Morocco, India (BIS), Singapore (Consumer Protection Safety Requirements), Cambodia, Hong Kong (EPSR)
Safety / Electromagnetic: USA (FCC), Canada (ICES), EU (CE), UK (UKCA), Ukraine, Morocco, Australia (RCM), Korea (MSIP), Japan (VCCI, Harmonics Regulation)
|
| Print Specification |
Print Speed:
720 × 720 dpi, 12 Pass (Colour): 0.89 m²/h
1,440 × 720 dpi, 16 Pass (White): 0.65 m²/h
Curing Method: LED-UV Type
Graphic Mode: Production (Colour): 0.68 m²/h; Quality (Colour): 0.5 m²/h
Text Mode: Production (Colour): 0.68 m²/h
|
| Dimensions & Weight |
Dimensions (W × D × H):
Printing: 699 × 426 (Cover Closed) / 942 (Cover Open) × 699 mm
Stowed: 699 × 426 × 699 mm
Weight: 59 kg
|
| Connectivity |
Interface: Super-Speed USB (USB 3.0 Spec), 100BASE-TX / 1000BASE-T / IEEE802.11 b/g/n/az/ac
Printer Language: ESC/P Raster
Memory: 1 GB
|
