| Printing: |
Print Head:PrecisionCore MicroTFP Printhead
Nozzle Configuration:9,600 Nozzles (400 nozzles x 24 channels x 1 head)
Maximum Print Resolution:2,400 x 1,200 dpi
Minimum Ink Droplet Size:3.5 pl
Print Speed:CAD (A1): Plain Paper 300x600dpi Line Draw/Draft: 16s, 600x600dpi Line Draw/Speed: 23s
CAD A0: Plain Paper 300x600dpi Line Draw/Draft: 28s, 600x600dpi Line Draw/Speed: 43s
Poster B0: Plain Paper 300x600dpi EPSON Vivid/Speed: 46s
B0: Plain Paper: 35s (Draft), 46s (Speed), 258s (High Quality), Premium Glossy Photo Paper 170gsm: 152s (Speed), 281s (Quality), 614s (Max Quality)
Line Accuracy:±0.1% or ±0.26 mm
Minimum Line Width:0.08mm*1 (0.02mm*2)
Margin (Roll Paper):Top, Bottom: Min. 3mm right, left: Min. 0mm3
Margin (Cut Sheet):Top: Min. 3mm, Bottom: Min. 12.7mm right, left: Min. 0mm3 |
| Ink: |
Ink Type:UltraChrome XD3 Pigment Ink
Colours:Cyan, Magenta, Yellow, Red, Matte Black, Photo Black |
| Consumables: |
Maintenance Box:Maintenance Box: C13S210115
Borderless Maintenance Box: C13S210116
Replacement Printer Cutter Blade:C13S210117
110ml Ink Cartridge:Cyan: C13T51F200
Magenta: C13T51F300
Yellow: C13T51F400
Photo Black Ink Cartridge: C13T51F100
Matte Black Ink Cartridge: C13T51F800
Red: C13T51FF00
350ml Ink Cartridge:Cyan: C13T50Y200
Magenta: C13T50Y300
Yellow: C13T50Y400
Photo Black Ink Cartridge: C13T50Y100
Matte Black Ink Cartridge: C13T50Y800
Red: C13T50YF00
700ml Ink Cartridge:Cyan: C13T50R200
Magenta: C13T50R300
Yellow: C13T50R400
Photo Black Ink Cartridge: C13T50R100
Matte Black Ink Cartridge: C13T50R800
Red: C13T50RF00
|
| Power: |
Rated Voltage:AC 100-240V 50/60Hz
Rated Current:3.4-1.6A
Electric Power Consumption:Operating: Approx. 70W
Ready: Approx. 32W
Sleep: Approx. 2.0W
Standby: Approx. 0.3W |
| Paper Handling: |
Media Thickness:Roll: 0.07mm – 0.8mm, Cut Sheet: 0.07mm – 0.8mm, Poster Board: 0.8mm – 1.5mm
Paper Path:Roll (Double Roll), Cut Sheet (Manual Feed), Poster Board (Manual Feed)
Borderless Print:Sizes (mm): 1118, 1030, 914, 841, 728, 700, 610, 594, 515, 508, 500, 432, 406, 356, 330, 300, 254
Maximum Roll Diameter / Weight:2/3” Core, Max. 170mm/12.5kg
Paper Width:Roll: Roll: 254 – 1,118mm
Cutsheet: 203 – 1,118mm |
| Environmental Characteristics: |
Media Thickness:Roll: 0.07mm – 0.8mm, Cut Sheet: 0.07mm – 0.8mm, Poster Board: 0.8mm – 1.5mm
Paper Path:Roll (Double Roll), Cut Sheet (Manual Feed), Poster Board (Manual Feed)
Borderless Print:Sizes (mm): 1118, 1030, 914, 841, 728, 700, 610, 594, 515, 508, 500, 432, 406, 356, 330, 300, 254
Maximum Roll Diameter / Weight:2/3” Core, Max. 170mm/12.5kg
Paper Width:Roll: Roll: 254 – 1,118mm
Cutsheet: 203 – 1,118mm |
| Connectivity: |
USB Interface:USB 3.0, Ethernet (100BASE-TX/1000BASE-T), Wi-Fi (IEEE802.11b/g/n)
Memory:4GB + 960GB (Option SSD)Mobile:Epson Smart Panel, Apple AirPrint
USB Direct:Supported Format: PDF, TIFF, JPEG, HP-GL/2, HP RTL
Printer Languages :ESC/R raster, HP-GL/2*5, HP RTL*5, Adobe PostScript 3, Adobe PDF 1.7
Wi-Fi Direct:Wi-Fi Direct (Simple AP)
Control Panel:4.3” Touch Screen |
| Dimensions and Weight: |
Dimensions (W x D x H):1,848 x 829 x 975mm
Weight:Approx. 155 kg
Printer Width:44″ |
| Operating System: |
Operating System:Windows XP (32bit/64bit) / Vista / 7 / 8 / 8.1 / 10 / 11 Windows Server 2003 SP2 or later / 2008 / 2012 / 2016 / 2019 / 2022 Mac OS X 10.6.8 or later |
