| Printing: |
Print Head:PrecisionCore MicroTFP Printhead
Nozzle Configuration:Nozzle Configuration: 9,600 Nozzles
Black: Pk:1,600, Mk:1,600
Colour: C:1,600, M:1,600, Y:1,600, Gray:1,600
Maximum Print Resolution:2,400 x 1,200 dpi
Minimum Ink Droplet Size:3.5pl
Print Speed:A1 Size Premium Glossy Photo Paper 170gsm, 1200dpi x 1200dpi
EPSON Standard (sRGB) / Quality: 111 sec
Minimum Line Width:0.08 mm*2 (0.02 mm*3)
Printing Method:PrecisionCore Inkjet Technology, Variable-Sized Droplet Technology
Margin (Roll Paper):Top, bottom: Min. 3mm
Right, left: Min. 0mm
(Might differ depending on applications/media)
Margin (Cut Sheet):Top: Min. 3mm
Bottom: Min. 12.7mm
Right, left: Min. 0mm
(Might differ depending on applications/media) |
| Ink: |
Ink Type:Pigment Ink
Colours:Cyan, Magenta, Yellow, Gray, Photo Black, Matte Black
Ink Brand Name:UltraChrome Pro 6 Ink
Ink Case:In Cartridge |
| Utility Software: |
Utility Software (Bundled in CD):Windows: Printer driver, EpsonNet Setup, EpsonNet Print, EpsonNet Config SE, Epson Manuals, Manual Launcher, LFP Print Plug-in for Office
Utility Software (Web delivery):Windows: Epson Media Installer, EpsonNet Setup Manager, Epson Device Admin, Epson Edge Dashboard, Epson Print Layout, Epson Print Automate, Epson Edge Print (Option), Epson Print Admin (Option), Order Controller
Mac: Printer driver, EpsonNet Config SE, Epson Manuals, Epson Media Installer, Epson Edge Dashboard, Epson Print, LayoutiOS/Android, Epson Smart Panel |
| Power: |
Rated Current:AC 100V 3.4AAC 100-240V 3.4-1.6A
Power Consumption:Operating: Approx. 75W, Ready: Approx. 32W,
Sleep: Approx. 2W, Standby: Approx. 0.3W
Supply Voltage:AC 100 – 240V, 50/60Hz |
| Paper Handling: |
Paper Feed Method:Friction Feed
Paper Path:Roll (Single Roll),
Cut Sheet (Manual Feed),
Poster Board (Manual Feed)
Borderless Sizes:254mm (10”), 300mm (11.8”), 330mm (13”), 356mm (14”), 406mm (16”), 432mm
(17”), 500mm (19”), 508mm (20”), 515mm (20.3”), 594mm (23”), 610mm (24”)
Paper Size & Thickness:Roll: 0.07 – 0.8 mm
Manual: Cut Sheet: 0.07 – 0.8 mm / Poster Board: 0.8 – 1.5 mm
Roll Paper Remaining:The remaining amount is managed by the barcode printed on roll paper
Maximum Roll Diameter / Weight:Max. 170 mm*4 / 6.8kg
Paper Width:Roll : 254 – 610 mm
Cut Sheet: 203 – 610 mm
Maximum Printing Area:91 m*5 |
| Environmental Characteristics: |
Temperature:Operating: 10°C to 35°C
Storage: -20°C to 40°CHumidity:Operating: 20% to 80% (no condensation)
Storage: 5% to 85% (no condensation) |
| Connectivity: |
Interfaces:SuperSpeed USB, 100BASE-TX/1000BASE-T/IEEE802.11b/g/n/ac, USB Memory Stick
USB Direct:Yes
Printer Language:ESC/P raster |
| Recommended System Requirements: |
Win PC System Requirements:Windows 11/10/8.1/8/7/Vista/XP (32/64bit) or later
CPU : Core 2 Duo 3.05GHz or more
Memory : Memory more than 1GB
HDD : Free space more than 32GBMac System Requirements:Mac OS X 10.6.8 or later, Mac OS 11 or later
CPU : Core 2 Duo 3.05GHz or more
Memory : Memory more than 4GB
HDD : Free space more than 32GB |
| General: |
Memory:4 GB
Acoustic Noise Level:Sound Pressure Level: Approx. 46 dB(A)
Sound Power Level: Approx. 6.3 B(A)
Control Panel:4.3″ Optical Touch Colour LCD |
| Dimensions and Weight: |
Weight:Approx. 115.2kg
Dimensions:Printing: 1,365 x 829 x 975 mm (W x D x H)
Stowed: 1,365 x 499 x 975 mm (W x D x H) |
