| Printing: |
Printing Technology:
MicroTFP Printhead
Nozzle Configuration:
9,600 nozzles (800 nozzles x 12 channels x 1 head)
Maximum Print Resolution:
2,400 x 1,200 dpi
Minimum Ink Droplet Size:
3.5pl
Print Speed:
219 sec (Level 1); 285 sec (Default) Premium Glossy Photo Paper 170gsm A1 size / ISO Bike
Printer Language:
ESC/P raster
Printing Method:
PrecisionCore Inkjet Technology, Variable-Sized Droplet Technology |
| Ink: |
Ink Type:
Epson UltraChromeTM PRO12 Pigment InkColours:
Cyan, Vivid Magenta, Yellow, Light Cyan, Vivid Light Magenta, Orange, Green, Violet, Photo Black, Matte Black, Gray, Light Gray
Ink Capacity:
350ml, 700ml |
| General: |
Dimensions:
Storage (W x H x D): 1,909mm x 1,218mm x 667mm
Printing (W x H x D): 1,909mm x 1,218mm x 2,211mm
Weight:
153.8kg |
| Printer Details: |
Options:
SpectroProofer, SpectroPhotoMeter, ILS30EP, Auto Take-Up Reel Unit, Hard Disk Unit, Adobe PostScript 3 Expansion Unit, Roll Media Adapter |
| Power: |
Rated Voltage:
AC100-240V 50/60Hz
Power Consumption:
Operating: Approx. 110W
Ready: Approx. 32W
Sleep: Approx. 3.4W
Power Off (Standby): Approx. 0.3W
Rated Current:
3.4 – 1.6A |
| Paper Handling: |
Paper Path:
Friction Feed
Paper Size & Thickness:
Width:
Roll Paper: 254mm to 620mm
Cutsheet: 210mm to 620mm
Thickness:
Roll: 0.08mm to 0.5mm
Cutsheet: 0.08mm to 1.5mm
Roll Dimensions:
2″ roll core media: Max. 103mm / 10kg
3″ roll core media: Max. 150mm / 10kg |
| Control Panel: |
Control Panel:
4.3-inch touch screen |
| Memory: |
Main:
2GB |
| Software: |
Standard (Bundled):
Windows Install Navi, Printer driver, EpsonNet Setup, EpsonNet Print, EpsonNet Config SE, Epson Software Updater, Epson Manuals, Manual Launcher, Epson Control Dashboard Mac Setup Navi EpsonNet Config SE Epson Software Updater
Option (Web Download):
Windows Install Navi, Web Installer, Firmware Updater, PS Driver, HDI Driver, XPS Driver, Epson Media Installer, EpsonNet Setup Manager, Epson Device Admin, Epson Edge Dashboard, Epson Edge Print, Epson Print Layout, LFP Accounting Tool, Adobe ICC Profiles, Mac Web Installer, Install Navi, Printer Driver, EpsonNet Config, Epson Software Updater, Uninstaller, Epson Manuals, Epson Media Installer, Firmware Updater, Linux, Printer Driver |
| Recommended System Requirements: |
Recommended System Requirements:
Windows XP/Vista/7/8/8.1 (32/64bit) or later
CPU: Core 2 Duo 3.05GHz;
Memory: Memory more than 1GB;
HDD: Free space more than 32GBMacintosh Mac OS X10.6.8 or later
CPU: Core 2 Duo 3.05GHz;
Memory: Memory more than 1GB;
HDD: Free space more than 32GB |
| Consumables: |
Maintenance Box:
Yes
Auto Cutter Spare Blade:
Yes
Borderless Replacement Pad Kit:
Yes
Ink Cartridge:
Yes |
| Printer Width: |
Printer Width:
44” |
| Printer Software on CD-ROM: |
Printer Drivers:
WindowsXP/Vista/7/8/8.1/10 (32/64bit) or later / MacOSX10.6.8 or later
Windows Server 2003 Standard/Standard *64bit, 2008 Standard/Standard *64bit /R2, 2012 or later
2003/2003 *64bit, 2008/2008R2 *64bit/2012 or later (Certification/Logo : Windows Server 2008/2008R2) |
| Acoustic Noise Level: |
Sound Pressure Level:
Operating: Approx. 49.5dB(A)
Sleep: Approx. 31.5dB(A)
Sound Power Level:
Approx. 7.5B(A) |
| Environmental Characteristics: |
Temperature:
Operating: 10°C to 35°C
Storage:
Packing: -20°C to 60°C
Unpacking: -20°C to 40°C
Humidity:
Operating: 20 to 80% (no condensation)
Storage: 5 – 85% (no condensation) |
| Connectivity: |
Interface:
USB Interface (Hi-Speed USB/USB), 1000BASE-T/100BASE-TX |
