| Printer |
Printer Type
5-Colour 36″ (914 mm)
Number of Nozzles
15,360 nozzles (MBK: 5,120 nozzles; BK, C, M, Y: 2,560 nozzles each)
Maximum Print Resolution
2,400 × 1,200 dpi
Nozzle Pitch
1,200 dpi (2 lines)
Line Accuracy
± 0.1% or less
Minimum Ink Droplet Size
5 pl
Ink Capacity
Sales Ink: 330 ml / 700 ml (MBK, BK, C, M, Y); Bundled Starter Ink: 330 ml (MBK) / 160 ml (BK, C, M, Y)
Ink Type
Pigment Ink
Printer Language
SG Raster, HP-GL/2, HP RTL, PDF (Ver. 1.7), JPEG (Ver. JFIF1.02)
Printing Solutions
Direct Print Plus, CPP PRISMAproduce Tech, Easy-PhotoPrint Editor, Canon PRINT (Mobile), Canon Print Service (Mobile), Free Layout Plus, PosterArtist Windows/Lite/Web
Management Solutions
Media Configuration Tool, Accounting Manager, Device Management Console, Quick Utility Box
|
| Standard Interfaces |
USB A Port
USB Memory (Direct Print)
USB B Port
Hi-Speed USB, Full Speed (12 Mbit/sec), High Speed (480 Mbit/sec), Bulk Transfer
Gigabit Ethernet
IEEE 802.3 10base-T, IEEE 802.3u 100base-TX, IEEE 802.3ab 1000base-T, SNMP, HTTP, FTP, TCP/IP (IPv4/IPv6)
Wireless LAN
IEEE802.11b/g/n, WPA-PSK (TKIP/AES), WPA2-PSK (TKIP/AES), WPA3-SAE (AES), WPA-EAP (AES), WPA2-EAP (AES), WPA3-EAP (AES)
|
| Memory & Storage |
System Memory
Standard: 128 GB, Physical: 2 GB
Hard Disk Drive
500 GB (Encrypted)
|
| Print Speed |
CAD Drawings, A0
26 sec [Fast (Custom Q5)], 1 min 6 sec [Standard]
Poster, A0
29 sec [Fast (Custom Q5)], 1 min 15 sec [Standard]
Heavyweight Coated Paper HG
Poster, A0: 2 min 34 sec [Standard]
Glossy Photo Paper HG 170
Poster, A0: 5 min 14 sec [Standard]
|
| Media Handling |
Media Feed and Output
Two Roll, Front Load, Front Output / Top Output; Cut Sheet: Front Load, Front Output
Media Width (Roll / Cut Sheet)
203.2 ～ 917 mm
Min. Printable Length
Roll Paper: Front Output: 203.2 mm, Top Output: 205 mm; Cut Sheet: 203.2 mm
Max. Printable Length
Roll Paper: 18 m; Cut Sheet: 610 mm
Maximum Outer Roll Diameter
175 mm or less
Borderless Printing Width
203.2 ～ 917 mm (Roll paper only)
Margins (Recommended Area)
Roll Paper: Top: 20 mm, Bottom: 3 mm, Side: 3 mm; Cut Sheet (Others): Top: 20 mm, Bottom: 20 mm, Side: 3 mm
Margins (Printable Area)
Roll Paper: Top: 3 mm, Bottom: 3 mm, Side: 3 mm; Roll Paper (Borderless Print): Top: 0 mm, Bottom: 0 mm, Side: 0 mm; Cut Sheet (Others): Top: 3 mm, Bottom: 20 mm, Side: 3 mm
|
| Dimensions & Weight |
Dimensions (W x D x H)
Main Unit: 1,548 x 762 x 1,126 mm (Basket Closed)
Main Unit + Paper Output Support + Top Output Guide: 1,548 x 1,293 x 1,428 mm (Basket Open), 1,548 x 960 x 1,189 mm (Basket Closed)
Weight
Main Unit: 205 kg; Main Unit + Paper Output Support + Top Output Guide: 206 kg
Packaged Dimensions (W x D x H)
Main Unit + Paper Output Support + Top Output Guide + Pallet: 1,704 x 946 x 1,373 mm
Packaged Weight
Main Unit with Basket + Paper Output Support + Top Output Guide + Pallet: 277 kg
|
| Power & Operating Requirements |
Power Supply
AC 100 – 240 V, 50 – 60 Hz
Power Consumption
Printing: Approx. 111 W; Sleep Mode: Approx. 2.1 W; Power Off: Approx. 0.1 W
Operating Environment
Temperature: 15 ～ 30 °C; Humidity: 10 ～ 80 % RH (no dew condensation)
Acoustic Sound
Acoustic Power: Operation: Approx. 70 dB; Acoustic Pressure: Operation: Approx. 52 dB (A), Standby: 35 dB (A) or less
|
| Accessories |
2″/3″ Roll Holder (Optional)
RH2-34
|
| Consumables |
Print Head
PF-06
Maintenance Cartridge
MC-30
Ink Tank
Matte Black / Black / Cyan / Yellow: PFI-8340 (330 ml) / PFI-8740 (700 ml); Magenta: PFI-8341 (330 ml) / PFI-8741 (700 ml)
|
