| Printer |
Printer Type
5-Colour, 36″ / 914 mm
Number of Nozzles
15,360 nozzles (MBK 5,120, Other Colours 2,560 each)
Maximum Print Resolution
2,400 x 1,200 dpi
Nozzle Pitch
1,200 dpi (2 lines)
Line Accuracy
± 0.1% or less
Ink Capacity
130 ml/300 ml (MBK/BK/C/M/Y)
Ink Type
Pigment Ink
Printer Languages
SG Raster, HP-GL/2, HP RTL, JPEG, CALS G4, PDF
|
| Printing Solutions |
Printer Driver (Win/Mac), Direct Print Plus, Free Layout Plus, PosterArtist, Wi-Fi Connection Assistant, PIXMA Cloud Link, Canon PRINT (Mobile), uniFlow server
|
| Management Solutions |
Media Configuration Tool, Accounting Manager, Device Management Console, Quick Utility Toolbox
|
| Standard Interfaces |
USB A (Direct Print), USB B (Hi-Speed), Network (Ethernet), Wi-Fi (802.11 b/g/n)
|
| Memory & Storage |
Memory: 128 GB (Physical Memory 2 GB)
Hard Disk: 500 GB (Encrypted)
|
| Display |
4.3 inch LCD TFT Colour |
| Print Speed (A1) |
CAD Drawing (Fast Q5 Mode): 17 sec (Landscape)
Poster (A0 Portrait, Standard Mode): 2 min 33 sec |
| Media Handling |
Roll Paper: Top Load, Front Output
Cut Sheet: Top Load, Front Output |
| Media Width & Thickness |
Roll: 203.2 mm – 917 mm
Cut Sheet: 203.2 mm – 917 mm
Thickness: 0.07 – 0.8 mm |
| Printable Lengths & Roll Diameter |
Min. Printable Length: Roll: 203.2 mm; Cut Sheet: 279.4 mm
Max. Printable Length: Roll: 18 m; Cut Sheet: 1,600 mm
Max. Outer Roll Diameter: 150 mm or less |
| Borderless Printing & Margins |
Supported for roll paper
Margins:
Roll Paper: 20 mm (Top), 3 mm (Sides)
Cut Sheet: 20 mm (Top/Bottom), 3 mm (Sides) |
| Dimensions & Weight |
Dimensions (W x D x H)
Main Unit: 1,285 x 748 x 439 mm
Main Unit + Stand + Basket:
Basket Opened: 1,285 x 885 x 1,060 mm
Basket Closed: 1,285 x 756 x 1,060 mm
Weight
Main Unit: 50 kg; With Stand & Basket: 65 kg
|
| Power & Operating Requirements |
Power Supply
AC 100–240V (50–60Hz)
Power Consumption
Printing: 69 W; Sleep Mode: 1.6 W; Power Off: 0.1 W
Operating Environment
Temperature: 15–30°C; Humidity: 10–80% RH (no condensation)
Noise Levels
Operation: 41 dB(A); Standby: 35 dB(A) or less
|
| Accessories |
Optional Printer Stand
2/3″ Roll Holder
Cutter Blade
|
| Consumables |
Ink Tank: PFI-8121 (130 ml)/PFI-8321 (300 ml)
Print Head: PF-06
Maintenance Cartridge: MC-31
|
| Scanner Specifications |
Scan Width: 36″
Max. Scan Length: 8 m (JPEG/PDF), 15.2 m (TIFF)
Max. Scan Speed: 3 ips (Colour at 200 dpi)
Optical Resolution: 1200 dpi
|
| System Controller |
OS: Windows 10 Enterprise LTSC 64 bit
Processor: Intel Pentium G5400T
Memory: 8 GB (DDR4)
Display: 15.6″ multi-touch
|
