| Printer |
Printer Type
5-Colour 24″ (610 mm)
Number of Nozzles
15,360 nozzles (MBK: 5,120; Other Colours: 2,560 each)
Maximum Print Resolution
2,400 x 1,200 dpi
Nozzle Pitch
1,200 dpi (2 lines)
Line Accuracy
±0.1% or less
Ink Capacity
130 ml / 300 ml (MBK/BK/C/M/Y)
Ink Type
Pigment Ink
Printer Language
SG Raster, HP-GL/2, HP RTL, JPEG (JFIF1.02), CALS G4
|
| Standard Interfaces |
USB B
Hi-Speed USB
Ethernet
10/100/1000Base-T
Wireless LAN
Wi-Fi
|
| Memory & Display |
Memory
2 GB
Display
4.3″ TFT Colour LCD
|
| Print Speed |
CAD (A1 Fast)
20 sec
Poster (A1 Standard)
1 min 23 sec
|
| Media Handling |
Media Width (Roll / Cut Sheet)
203.2 mm – 610 mm
Media Thickness (Roll / Cut Sheet)
0.07 – 0.8 mm
Minimum Printable Length
Roll: 203.2 mm; Cut Sheet: 279.4 mm
Maximum Printable Length
Roll: 18 m; Cut Sheet: 1,600 mm
Maximum Outer Roll Diameter
150 mm or less
Media Core Size
2″ / 3″
Borderless Printing
Supported (Roll Paper only)
Margins
Roll: 3 mm (all sides); Cut Sheet: Top 3 mm, Bottom 20 mm, Sides 3 mm
|
| Dimensions & Weight |
Dimensions (W x D x H)
Main Unit: 978 x 748 x 439 mm
With Stand & Basket (Basket Opened): 978 x 885 x 1,060 mm
With Stand & Basket (Basket Closed): 982 x 756 x 1,060 mm
Weight
Main Unit: 42 kg; With Stand & Basket: 55 kg; Packaged: Up to 96 kg
|
| Power & Operating Requirements |
Power Supply
AC 100–240V (50–60Hz)
Power Consumption
Printing: 62 W or less; Sleep Mode: 1.6 W or less; Power Off: 0.1 W or less
Operating Environment
Temperature: 15–30°C; Humidity: 10–80% RH (no condensation)
Noise Levels
Operation: 41 dB(A); Standby: 35 dB(A) or less
|
| Scanner |
Scanner Type
SingleSensor with multiple LED illumination
Optical Resolution
600 dpi
Scan Width
Max: 24″ (610 mm); Min: 6″ (150 mm)
Max. Scan Length
109″ (2,768 mm)
Document Thickness
0.07 – 0.8 mm
Scan Speed (Colour / Mono)
Draft (200 dpi): 1 ips / 3 ips; Standard (300 dpi): 0.5 ips / 1.5 ips; Best (600 dpi): 0.33 ips / 1 ips
Copy & Scan Functions
Scan to USB (TIFF, JPG, PDF); Scan to PC; Copy & Save concurrently
|
