| Printer |
Printer Type: 4-Colour 24″ (610 mm)
Number of Nozzles: 4,352 nozzles (BK: 1,280 / C, M, Y: 1,024 each)
Maximum Print Resolution: 2,400 × 1,200 dpi
Nozzle Pitch: 1,200 dpi (2 lines)
Line Accuracy: ± 0.1% or less
Ink Capacity: Sales Ink: 70 ml (BK, C, M, Y); Bundled Starter Ink: 70 ml (BK, C, M, Y)
Ink Type: Pigment Ink
Printer Language: SG Raster (Swift Graphic Raster)
Supported File Types (USB Memory): PDF (via ScanToPDF, MP Navigator, My Image Garden, IJ Scan Utility), JPEG (Exif ver2.2/2.21/2.3)
|
| Software / Solutions |
Canon PRINT Inkjet/SELPHY (iOS/Android), Canon Print Service (Android), Free Layout Plus, PosterArtist, Direct Print Plus, PIXUS/PIXMA Cloud Link, ChromeOS
Management Tools: Media Configuration Tool, Quick Utility Toolbox, Wi-Fi Connection Assistant, Printer Update Utility
|
| Standard Interfaces (Built-in) |
USB A Port: USB Memory (Direct Print): PDF / JPEG (Exif ver2.2/2.21/2.3)
USB B Port (Series B, 4 pins): Hi-Speed USB, Full Speed (12 Mbit/sec), High Speed (480 Mbit/sec), Bulk Transfer
Wired LAN: IEEE 802.3 10base-T, IEEE 802.3u 100base-TX; Protocols: SNMP, HTTP, TCP/IP (IPv4/IPv6)
Wireless LAN: IEEE802.11a/b/g/n/ac; Security: WPA-PSK, WPA2-PSK, WPA3-SAE, WPA/WPA2/WPA3-EAP (AES)
|
| Memory |
Standard Memory: 1 GB
|
| Print Speed |
Plain Paper (CAD Drawing): 30 sec (Draft, Monochrome)
|
| Scanner |
Scanner Type: Flatbed (CIS Scanner)
Optical Resolution: 1,200 x 2,400 dpi
Greyscale: 16 bit / 8 bit
Colour: RGB 16 bit / 8 bit
Scan Speed (300 dpi): Greyscale / Monochrome: 1.5 ms/line; Colour: 3.5 ms/line
Max Document Size: A4/LTR (216 x 297 mm)
|
| Media Handling |
Media Feed and Output: Roll Paper: One Roll, Top Load, Front Output; Cut Sheet: Top Load, Front Output
Media Width: Roll: 297 ~ 610 mm; Cut Sheet: 89 ~ 297 mm
Media Thickness: 0.08 ～ 0.28 mm
Media Core Size: 2 inch core
Printable Length: Minimum (Roll): 203.2 mm; Minimum (Cut Sheet): 127 mm; Maximum (Roll): 4 m; Maximum (Cut Sheet): 1,200 mm
Maximum Outer Roll Diameter: 110 mm or less
Margins (Recommended & Printable Area): Roll Paper: Top/Bottom: 5 mm, Left/Right: 5 mm; Minimal Margin Print (Roll): Top/Bottom: 0 mm, Left/Right: Approx. 0.5 mm; Cut Sheet: 5 mm on all sides
|
| Dimensions & Weight |
Main Unit (W x D x H):
968 × 613 × 395 mm (ASF Opened, OP Opened)
968 × 553 × 395 mm (ASF Opened, OP Closed)
968 × 593 × 245 mm (ASF Closed, OP Opened)
968 × 533 × 245 mm (ASF Closed, OP Closed)
With Stand + Basket (SD-24):
Opened: 968 × 868 × 1,024 mm
Closed: 968 × 720 × 874 mm
With Desktop Basket (BU-06):
Opened: 968 × 845 × 1,115 mm
Closed: 968 × 595 × 965 mm
Weight: Main Unit: 34 kg; With Stand + Basket (SD-24): 44 kg; With Desktop Basket (BU-06): 35 kg
Packaged Dimensions:
Main Unit: 1,120 × 726 × 406 mm
Stand + Basket (SD-24): 1,058 × 826 × 270 mm
Desktop Basket: 798 × 301 × 111 mm
Packaged Weight: Main Unit: 46 kg; Stand + Basket (SD-24): 20 kg; Desktop Basket: 2.0 kg
|
| Power & Operating Requirements |
Power Supply: AC 100 – 240 V, 50 – 60 Hz
Power Consumption: Copy Operation: Approx. 28 W; Sleep Mode: Approx. 1.7 W; Power Off: Approx. 0.07 W
Operating Environment: Temperature: 15 ～ 30°C; Humidity: 10 ～ 80% RH (no dew condensation)
|
| Acoustic Sound |
Acoustic Power: Approx. 6.0 Bels
Acoustic Pressure: Operation: Approx. 41.5 dB (A); Standby: 35 dB (A) or less
|
| Accessories |
Printer Stand (Optional): SD-24
Desktop Basket: BU-06
|
| Consumables |
Ink Bottle: PFI-050 (70 ml) – Black, Cyan, Magenta, Yellow
Print Head: PF-08
Maintenance Cartridge: MC-32
|
