| Printer |
Printer Type
7-Colour, 24″ / 610 mm
Number of Nozzles
18,432 nozzles
Maximum Print Resolution
2,400 x 1,200 dpi
Nozzle Pitch
600 dpi × 2 lines
Line Accuracy
± 0.1% or less
Minimum Ink Droplet Size
4 picolitres per colour
Ink Capacity
160 ml / 330 ml / 700 ml (Sales Ink)
330 ml (Matte Black, Cyan, Magenta, Yellow, Orange)
160 ml (Photo Black, Grey) (Bundled Starter Ink)
Ink Type
Pigment Ink: Matte Black, Photo Black, Cyan, Magenta, Yellow, Grey, Orange
|
| Printer Languages |
SG Raster, PDF (Ver. 1.7), JPEG (Ver. JFIF1.02) |
| Printing Solutions |
Direct Print Plus, Easy-PhotoPrint Editor, Canon PRINT, Canon Print Service, Free Layout Plus, PosterArtist, Professional Print & Layout |
| Management Solutions |
Media Configuration Tool, Accounting Manager, Device Management Console, Quick Utility Toolbox |
| Standard Interfaces |
USB A (Direct Print), USB B (Hi-Speed), Gigabit Ethernet (1000 Base-T), Wireless LAN (802.11n/g/b) |
| Memory & Storage |
Memory: 3 GB
Hard Disk: 500 GB (Encrypted) |
| Printing Speed |
Heavyweight Coated Paper HG (A1): 1 min 23 sec
Glossy Photo Paper HG (A1): 2 min 43 sec |
| Dimensions & Weight |
Packaged Dimensions (Main Unit + Pallet): 1,338 x 912 x 1,042 mm (Approx. 125 kg)
Main Unit Dimensions: 1,110 x 734 x 628 mm (Approx. 83 kg)
Main Unit + Stand + Basket: 1,110 x 984 x 1,168 mm (Basket Opened) (Approx. 100 kg) |
| Media Handling |
Roll Paper: Upper Load, Front Output
Cut Sheet: Front Load, Front Output
Media Width: 152.4 mm – 610 mm
Media Thickness: 0.07 mm – 0.8 mm
Max Printable Length: Roll Paper: 18 m; Cut Sheet: 1.6 m |
| Borderless Printing |
Supported for roll paper in specific widths (e.g., 515 mm, 594 mm, A1) |
| Power & Operating Requirements |
Power Supply: AC 100 – 240 V, 50 – 60 Hz
Power Consumption:
Printing: 91 W
Sleep Mode: 1.7 W
Power Off: 0.1 W
Operating Environment:
Temperature: 15 ~ 30°C
Humidity: 10 ~ 80% RH (no dew condensation) |
| Noise Levels |
Operation: 48 dB(A)
Standby: 35 dB(A) or less |
| Accessories |
Optional Printer Stand (SD-21), Roll Unit (RU-23), 2″/3″ Roll Holder (RH2-29) |
